    PLC S7-300 Power Supply Module 6ES7 307-1EA01-0AA0 PS307 24 V/5 A

    Ask Lasest Price
    Brand Name : Jetacon
    Certification : UL, CE
    Model Number : 6ES7 307-1EA01-0AA0
    Price : Get latest price
    Delivery Time : 7-20 working days
    Payment Terms : T/T, L/C, Paypal, Payoneer
    Supply Ability : 1KK poles monthly
    • Product Details
    • Company Profile

    PLC S7-300 Power Supply Module 6ES7 307-1EA01-0AA0 PS307 24 V/5 A

    Type Number Available :

    6ES7307-1EA01-0AA0
    S7-300
    Stabilized Power Supply PS307
    Input: 120/230 V AC
    Output: DC 24 V DC/5 A

    6ES7307-1BA01-0AA0
    S7-300
    Stabilized Power Supply PS307
    Input: 120/230 V AC
    Output: DC 24 V DC/2 A

    -

    Technical specifications
    ProductPS 307
    Power supply, type24 V/5 A
    Input
    Input1-phase AC
    Supply voltage / 1 / at AC / nominal value120 V
    Supply voltage / 2 / at AC / nominal value230 V
    Output
    OutputControlled, isolated DC voltage
    Rated voltage Vout DC24 V
    Total tolerance, static ±3 %
    Static mains compensation, approx.0.1 %
    Static load balancing, approx.0.5 %
    Residual ripple peak-peak, max.50 mV
    Residual ripple peak-peak, typ.10 mV
    Spikes peak-peak, max. (bandwidth: 20 MHz)150 mV
    Spikes peak-peak, typ. (bandwidth: 20 MHz)20 mV

    -
